Start here
MITSUBISHI PS21962-T/-AT/-CT/-TW Manual
This manual describes the dual‑in‑line package intelligent power module (DIPIPM) PS21962 series, including the T, AT, CT and TW variants. It outlines the package dimensions, terminal codes, and internal functional block diagram, and gives guidance on wiring and recommended external protection circuits.
Key sections cover maximum electrical ratings, control and protection parameters, mechanical characteristics, recommended operating conditions, timing charts for protective functions, and example application circuits. The document is intended for designers and engineers integrating the module into three‑phase inverter drives for small‑power motor control.
Mitsubishi PS21962 specifications
| Supply voltage (P‑N) | 450 V (typical) |
|---|---|
| Collector‑emitter voltage (VCES) | 600 V |
| Collector current (Ic) | 5 A (typical), 10 A (peak) |
| Power dissipation per chip | 21.3 W |
All Mitsubishi PS21962 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum collector‑emitter voltage rating?
The module is rated for a collector‑emitter voltage of 600 V.
What is the recommended control supply voltage range?
The control supply voltage should be between 13.5 V and 16.5 V.
