Start here
Mitsubishi AJ65VBTCU-68DAV Digital-Analog Converter Module User Manual
This manual explains the specifications, handling, programming methods and other details of the AJ65VBTCU-68DAV digital‑analog converter module, which converts 16‑bit signed binary data to analog voltage or current outputs. Key features include high accuracy (±0.3% at 0‑55 °C), selectable output range per channel, high resolution (1/±4000) and four analog output channels.
The manual also contains extensive safety and installation precautions, wiring guidelines, maintenance instructions, and warranty information to ensure safe and reliable operation of the module in a CC‑Link system.
Mitsubishi AJ65VBTCU-68DAV specifications
| Accuracy (0‑55 °C) | ±0.3% of full‑scale output |
|---|---|
| Accuracy (25 °C ± 5 °C) | ±0.2% of full‑scale output |
| Output range | Selectable per channel |
| Resolution | 1/±4000 |
| Number of analog output channels | 4 |
| Ambient temperature range | 0 °C to 55 °C |
| Ambient humidity range | 10 %RH to 90 %RH |
Source: Mitsubishi AJ65VBTCU-68DAV Digital-Analog Converter Module User Manual
All Mitsubishi AJ65VBTCU-68DAV documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What safety precautions must be taken before using the AJ65VBTCU-68DAV module?
Read all safety precautions in the manual, configure a safety circuit, keep wiring at least 100 mm apart, and always switch off power before installation.
From: Mitsubishi AJ65VBTCU-68DAV Digital-Analog Converter Module User Manual
How many analog output channels does the AJ65VBTCU-68DAV have?
The module provides four analog output channels.
From: Mitsubishi AJ65VBTCU-68DAV Digital-Analog Converter Module User Manual
