Intersil HI-546 Manuals

ManualLib has 3 documents for the Intersil HI-546: 2 datasheets. Every file can be read online or downloaded as a PDF for free.

Datasheet 2

Key facts

Model
HI-546
Industry
Industrial
Documents
3
Languages
EN
Last added
2012-10-17

Start here

INTERSIL HI9P0546-9Z Datasheet

INTERSIL HI9P0546-9Z Datasheet

Datasheet 24 pages · 528 KB · EN

The document describes a family of analog multiplexers (HI-546, HI-547, HI-548, and HI-549) fabricated using 44V Dielectrically Isolated CMOS technology. These devices feature active overvoltage protection that allows analog input levels to exceed power supplies by up to 70V peak-to-peak without damaging the device or disturbing other channels.

Read online

Intersil HI-546 specifications

Analog Overvoltage Protection Level70V P-P
Maximum Power Supply Voltage44V
Analog Signal Range±15V
Typical Access Time500ns
Typical Standby Power7.5mW
Maximum Junction Temperature (Ceramic Packages)175 °C

Source: INTERSIL HI9P0546-9Z Datasheet

All Intersil HI-546 documents by type

Datasheet 2

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What is the temperature range for the HI-9P0546-9Z model?

The operating temperature range is -40 to 85 °C.

From: INTERSIL HI9P0546-9Z Datasheet

Are these multiplexers RoHS compliant?

Yes, Pb-Free Plus Anneal versions are available and are RoHS Compliant.

From: INTERSIL HI9P0546-9Z Datasheet

What is the maximum analog overvoltage protection level?

The devices provide active overvoltage protection up to 70V peak-to-peak.

From: intersil HI-546 HI-547 HI-548 HI-549 Data Sheet(1)

What is the maximum power supply voltage?

The maximum power supply voltage is ±44V.

From: intersil HI-546 HI-547 HI-548 HI-549 Data Sheet(1)

What analog input voltage can the HI‑546/547/548/549 tolerate?

The devices can withstand constant 70 Vp‑p levels with +15 V supplies.

From: Intersil HI-546/HI-547/HI-548/HI-549 Datasheet

Are the HI‑546 series parts RoHS compliant?

Yes, they are Pb‑Free Plus Anneal products and are RoHS compliant.

From: Intersil HI-546/HI-547/HI-548/HI-549 Datasheet
