Intersil ISL6324 Dual PWM Hybrid Controller Datasheet
The ISL6324 is a monolithic dual PWM hybrid controller that powers AMD SVI and PVI split‑plane processors. It integrates two synchronous buck converters, internal MOSFET drivers and an I²C interface for programmable voltage offsets, over‑voltage and over‑current protection.
The document provides ordering information, pin‑out diagrams, typical SVI and PVI application schematics, absolute maximum ratings, detailed electrical specifications, layout guidelines, thermal‑management recommendations and a package outline drawing.
Intersil ISL6324 specifications
| Switching Frequency (selectable) | up to 1 MHz |
|---|---|
| Package | 48‑lead QFN 7 × 7 mm (L48.7x7) |
| Gate Drive Bias Range | 5 V to 12 V |
Source: Intersil ISL6324A Datasheet
All Intersil ISL6324 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum switching frequency supported by the ISL6324?
The controller supports selectable switching frequencies up to 1 MHz.
Does the ISL6324 include over‑current protection?
Yes, the device includes over‑current protection with defined trip levels for average and individual channel operation.
What is the maximum switching frequency of the ISL6324A?
The selectable switching frequency can be set up to 1 MHz.
What package options are available for the ISL6324A?
The device is offered in a 48‑lead QFN package measuring 7 mm × 7 mm (part numbers ISL6324ACRZ and ISL6324AIRZ).
