Start here
intersil HI-674A/883 handbook
The HI‑574A and HI‑674A are complete 12‑bit analog‑to‑digital converters with integrated reference, clock, and microprocessor‑compatible digital interface. They offer both unipolar and bipolar input ranges and feature low‑noise, current‑mode signal transmission.
The document lists detailed electrical specifications, timing diagrams, pin descriptions, and mechanical package dimensions for the 28‑lead PDIP and SBDIP versions, along with ordering numbers and absolute maximum ratings for safe operation.
Intersil HI-674A specifications
| Resolution | 12‑bit |
|---|---|
| Supply Voltage | +5V and +12V to +15V |
| Package | 28‑lead PDIP or SBDIP |
| Logic Input High Level | +2.4 V to +5.5 V |
Source: intersil HI-674A/883 handbook
All Intersil HI-674A documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the supply voltage range for the HI‑574A/HI‑674A?
The devices operate from a +5 V logic supply and a +12 V to +15 V analog supply.
How many pins does the package have?
Both devices are offered in a 28‑lead dual‑in‑line package (PDIP or SBDIP).
What is the resolution of the HI-574A and HI-674A converters?
Both devices provide a maximum resolution of 12 bits.
From: Intersil HI-574A / HI-674A 12‑Bit A/D Converter Datasheet
What supply voltages are required for the HI-574A and HI-674A?
They operate from +5 V and +12 V to +15 V, with typical power dissipation of 385 mW at 12 V.
From: Intersil HI-574A / HI-674A 12‑Bit A/D Converter Datasheet
