Intersil ISL6208 MOSFET Driver Datasheet
The ISL6208 is a high‑frequency, dual MOSFET driver optimized for synchronous‑rectified buck converter topologies. It delivers 4 A typical sink current and includes features such as adaptive shoot‑through protection, three‑state PWM input, and an internal bootstrap diode.
The document details electrical specifications, thermal information, package options (SOIC‑8 and 3 × 3 mm QFN), layout recommendations, and typical performance waveforms, helping designers integrate the driver into mobile computing power supplies and other high‑frequency DC‑DC converters.
Intersil ISL6208 specifications
| Typical sinking current | 4 A |
|---|---|
| Maximum junction temperature (plastic package) | +150 °C |
| Propagation delay (UGATE rise) | 8 ns |
All Intersil ISL6208 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the typical sink current of the ISL6208?
The driver provides a typical sinking current of 4 A.
What does the three‑state PWM input do?
It adds a shutdown window to the PWM input that disables the output drivers when the PWM signal stays within the window for a set hold‑off time.
What is the typical sink current of the ISL6208A?
The driver provides a typical sinking current of 4 A.
What is the maximum switching frequency supported?
The device supports switching frequencies up to 2 MHz.
