Analog Devices AD8509/AD8511 LCD Reference Buffer Datasheet
The AD8509 and AD8511 are CMOS LCD reference buffers designed to drive 64‑gray‑scale column drivers. Each device provides A/B inputs for selecting between two reference voltages and can source up to 300 mA per channel, making them suitable for high‑speed gamma‑correction applications. They operate from a single 3.3 V to 6.5 V supply and are stable with capacitive loads up to 1000 pF.
Both parts are offered in 48‑lead Pb‑free TSSOP and LFCSP packages and are rated for operation from –40 °C to +85 °C. The datasheet includes pin configurations, functional block diagrams, typical performance curves, and absolute maximum ratings for designers.
Analog Devices AD8509 specifications
| Supply Voltage Range | 3.3 V to 6.5 V |
|---|---|
| Maximum Supply Voltage | 7 V |
| Operating Temperature Range | –40 °C to +85 °C |
| Output Short‑Circuit Current | 120 mA to 350 mA |
| Output High Voltage | +20 V |
| Output Low Voltage | –20 mV |
| Input Bias Current | 50 nA |
| Offset Voltage | 20 mV |
| Supply Current (AD8509) | 8.5 mA @ 2.5 V |
| Supply Current (AD8511) | 10 mA @ 2.5 V |
| Thermal Resistance (TSSOP) | 115 °C/W |
| Thermal Resistance (LFCSP) | 125 °C/W |
Source: Analog Devices AD8509/AD8511 LCD Reference Buffer Datasheet
All Analog Devices AD8509 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the supply voltage range for the AD8509/AD8511?
The devices operate from 3.3 V up to 6.5 V.
From: Analog Devices AD8509/AD8511 LCD Reference Buffer Datasheet
How many channels does each part provide?
The AD8509 provides 9 channels and the AD8511 provides 11 channels.
From: Analog Devices AD8509/AD8511 LCD Reference Buffer Datasheet
What is the supply voltage range for the AD8509 and AD8511?
Both devices operate from a single supply voltage of 3.3 V to 6.5 V.
From: ANALOG DEVICES arithmetic amplifier seriesAD8511 AD8509 handbook
How much output current can the AD8509 and AD8511 deliver?
They can deliver up to 300 mA of output current.
From: ANALOG DEVICES arithmetic amplifier seriesAD8511 AD8509 handbook
