TOSHIBA LTM08C351S handbook(1)(1)
This handbook describes the 26 cm (10.4") color TFT‑LCD module LTA104D183F, including its mechanical dimensions, electrical and optical specifications, and touch‑panel features. It also lists recommended operating conditions, absolute maximum ratings, and safety precautions for handling the module.
The document contains a block diagram, timing charts, connector pin assignments, and a detailed safety section that outlines disassembly warnings, handling of liquid crystal material, and required protection circuits. It is intended for designers and integrators who need to incorporate the module into equipment.
Toshiba LTM08C351S specifications
| Dimensional Outline (typ.) | 242.0 mm (W) × 178.45 mm (H) × 15.4 mm (D) |
|---|---|
| Number of Pixels | 800 × 600 |
| Typical Supply Voltage | 3.3 V |
| Contrast Ratio (typ.) | 450 |
| Luminance (typ.) | 320 cd/m² |
| Backlight Lamp MTBF | 50,000 h |
Source: TOSHIBA LTM08C351S handbook(1)
