STMicroelectronics STEVAL-IFP016V2 IO-Link Master Transceiver Demonstration Board Data Brief
The STEVAL-IFP016V2 is a demonstration board designed for IO-Link communication, featuring a programmable output stage and support for COM1, COM2, and COM3 modes. It is based on the L6360 chip and includes a 30-pin connector for control and programming via an external demonstration board.
Read onlineSTMicroelectronics STEVAL-IFP016V2 specifications
| Supply voltage | 18 V to 32.5 V |
|---|---|
| Digital input | 5 mA IO-Link |
| Regulator | 3.3 V/5 V, 50 mA |
| Compatible interfaces | COM1, COM2 and COM3 |
Source: STMicroelectronics STEVAL-IFP016V2 IO-Link Master Transceiver Demonstration Board Data Brief
All STMicroelectronics STEVAL-IFP016V2 documents by type
How to use the product for one specific task, with worked examples.
- ST AN4075 handbook 23 p
Questions answered in these manuals
What supply voltage range does the STEVAL-IFP016V2 support?
The board supports a supply voltage from 18 V to 32.5 V.
From: STMicroelectronics STEVAL-IFP016V2 IO-Link Master Transceiver Demonstration Board Data Brief
What is the rated current for the IO-Link digital input?
The board provides a 5 mA IO-Link digital input.
From: STMicroelectronics STEVAL-IFP016V2 IO-Link Master Transceiver Demonstration Board Data Brief
What demonstration boards is the STEVAL-IFP016V2 compatible with?
It works in combination with the STEVAL-PCCO09V2 or STEVAL-PCCO09V1 demonstration board.
From: ST AN4075 handbook
What IO-Link communication modes does the L6360 support?
The L6360 supports COM1 (4.8 kbaud), COM2 (38.4 kbaud), and COM3 (230.4 kbaud) modes.
From: ST AN4075 handbook
