Key facts
- Brand
- Yamaha
- Model
- 02R96
- Documents
- 6
- Languages
- EN
- Last added
- 2012-07-02
Start here
Yamaha 02R96 V2.2 Supplementary Manual
This document serves as a supplementary guide for the Yamaha 02R96 mixing console running System Software Version 2.20. It outlines specific changes and additions introduced in this version compared to previous releases (up to V2.11), including new Add-On Effects Packages and GPI OUTPUT parameters.
Read onlineYamaha 02R96 specifications
| Display Resolution (Windows) | 1024 x 768 pixels, 256 colors or higher |
|---|---|
| Display Resolution (Macintosh) | 1024 x 768 pixels, 256 colors or higher |
| Memory (Windows) | 512 MB or more of free memory |
| Memory (Macintosh) | 256 MB or more |
| Hard Disk Space (Windows) | 30 MB or more of free space |
| Hard Disk Space (Macintosh) | 30 MB or more of free space |
| Processor (Macintosh) | Macintosh G4 or better |
Source: Yamaha Studio Manager V2 Installation Guide for DM2000/02R96/DM1000/01V96
All Yamaha 02R96 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
Do I need to buy extra effects packages for this console?
No, you do not need to purchase optional Add-On Effects packages because the 02R96 VCM features these built-in effects.
From: Yamaha 02R96 VCM Digital Mixing Console Extra Effects List
Where can I find detailed information on the extra effects?
Detailed information is available in the PDF manuals located on the included CD-ROM.
From: Yamaha 02R96 VCM Digital Mixing Console Extra Effects List
What new Add-On Effects Packages are available in Version 2.20?
The AE041 Surround Post Package and the AE051 Vintage Stomp Package are now available.
What is the minimum version required for the 02R96 Editor?
You must update the 02R96 Editor to version 2.1.2 or higher (Studio Manager version 2.1 or higher).
Can I change parameters when using the THXD or THXF presets?
No, if you select preset THXD or THXF, you cannot change the parameters.
What are the available options for the Oscillator parameter in Speaker Setup?
You can choose from PINK NOISE, 500-2K (pink noise through a 500 Hz to 2 kHz BPF), 1K (1 kHz sinewave), or 50 Hz (50 Hz sinewave).
