Start here
Yamaha AVS-10 Electone Voice Expander User's Guide
The Yamaha AVS-10 is a combination voice expander designed for Electone keyboards. It comes preset with 12 voices created by the AWM Tone Generator to enhance total quality and versatility. The device allows users to add effects such as Touch, Sustain, Pan, Reverb, and Transposition to their instrument.
Read onlineYamaha S10e specifications
| Nominal Impedance | 8Ω |
|---|---|
| Frequency Response (S10e) | 65 Hz to 14 kHz |
| Power Capacity NOISE (S12e/S12Me) | 125 W |
| Dimensions (S15e) | 486 x 667 x 367 mm |
Source: Yamaha S10e/S12e/S15e/S12Me Speaker Systems Owner's Manual
All Yamaha S10e documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the recommended power-up sequence for the system?
Always turn the power amp on last to avoid loud, damaging pops that can damage speakers.
From: Yamaha S10e/S12e/S15e/S12Me Speaker Systems Owner's Manual
Can multiple speaker systems be connected together?
Yes, they can be daisy-chained because the input terminals are internally connected in parallel.
From: Yamaha S10e/S12e/S15e/S12Me Speaker Systems Owner's Manual
How do I set the Touch Sensitivity for the first time?
Turn ON the POWER switch while holding down the specific ENSEMBLE button corresponding to your Electone model (UPPER, LOWER, or PEDALS).
What is the AVS-10 and what does it provide for an Electone?
The AVS-10 is a Voice Expander that comes preset with data from 12 voices created by the AWM Tone Generator to enhance total quality and versatility.
