Key facts
- Brand
- Yamaha
- Model
- MP-1
- Category
- Other Electronics
- Documents
- 4
- Languages
- EN
- Last added
- 2012-06-12
Start here
Yamaha DMP11 Digital Mixing Processor Operation Manual
The Yamaha DMP11 is an all-digital signal processing unit that integrates an 8 x 2 digital line-level mixer with high-performance internal digital effects. It features 96 internal memories for storing complete system configurations, allowing for instant scene changes. The unit supports MIDI control for automating mixing and effect operations.
Read onlineYamaha MP-1 specifications
| Input/Output Configuration | Mono-input/stereo-out processor |
|---|---|
| Frequency Response | 20 Hz — 20 kHz |
| Pre-programmed Effects | 100 |
| RAM Memory Locations | 50 |
Source: Yamaha EMP100 Multi-Effect Processor Operation Manual
All Yamaha MP-1 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What power supply should be used?
The EMP100 should only be powered using the supplied Yamaha AC Adaptor.
How long does the memory backup battery last?
The backup battery is designed to retain memory contents for approximately 5 years.
How many internal memories does the DMP11 have?
The DMP11 features 96 internal memories which can store all console parameters.
From: Yamaha DMP11 Digital Mixing Processor Operation Manual
Can the DMP11 be cascaded with other units?
Yes, if 8 inputs aren't enough, the DMP11 permits digital cascading of 2 or more units.
From: Yamaha DMP11 Digital Mixing Processor Operation Manual
What type of batteries does the PortaSound MP-1 use?
It uses six 1.5V AM 2, SUM-2, "G" size, R-14, or equivalent alkaline batteries.
How do I know when the internal batteries need replacing?
When the internal batteries are weak and need replacing, the Power-on light flashes on and off.
