Yamaha R100 Reverb Processor Operation Manual
The Yamaha R100 is a digital reverb processor featuring 60 pre-programmed effects ranging from subtle to dynamic sounds. It includes stereo outputs for dramatic separation and allows users to edit four parameters per program for custom sound creation.
This operation manual provides instructions on connecting the unit, selecting effect programs via the front panel or MIDI, bypassing effects using a footswitch, and editing specific parameters such as decay time and feedback levels.
Yamaha R100 specifications
| Dynamic Range | 75dB |
|---|---|
| Reverberation Time (Mode 1) | 1.5 sec |
| Reverberation Time (Mode 4) | 2.4 sec |
| Dimensions | 480 x 45 x 311.5 mm |
| Weight | 4.8 kg |
All Yamaha R100 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Yamaha R1000 Digital Reverberation Operating Manual 8 p
- Yamaha R100 Reverb Processor Operation Manual 72 p
- Yamaha MSR100 Powered Speaker Owner's Manual 7 p
- Yamaha MSR100 Powered Speaker Owner's Manual 9 p
- Yamaha DR100 Digital Reverb Operation Manual 16 p
- Yamaha PSR-100 PortaTone Owner's Guide 10 p
- Yamaha HR-1000B Bass Amplifier Owner's Manual 4 p
- Yamaha DSR-1000/2000 Owner's Manual 29 p
- Yamaha R-1000 Stereo Receiver Owner's Manual 16 p
- Yamaha DSR-100PRO Natural Sound Digital Surround Decoder Operation Manual 40 p
- Yamaha CDR1000 Professional Audio CD Recorder Owner’s Manual 67 p
- Yamaha MSR100 Powered Speaker Owner's Manual 9 p
Questions answered in these manuals
What are the four reverb time settings?
The unit offers four reverb time settings: 1.5, 1.6, 2.3, and 2.4 seconds.
Can I use a foot switch?
Yes, the unit has a foot switch terminal for remote operation of bypass on/off switching.
Can I use any AC adapter?
No, only the supplied Yamaha PA-1C (or PA-1) AC Adaptor should be used.
How many pre-programmed effects does the R100 include?
The unit comes with 60 superb pre-programmed Yamaha digital effects.
What is the maximum output power of the amplifier?
The internal power amplifier delivers 100 watts.
What are the required clearances around the speaker for ventilation?
You must leave 30 cm of space on the sides and back, and 39 cm on top.
