Yamaha PSR-A1000 Owner's Manual
This Owner's Manual for the Yamaha PSR-A1000 includes four main sections: Introduction, Quick Guide, Basic Operation, and Reference, along with a separate Data List. It explains how to use the instrument's advanced functions and provides detailed settings instructions.
Read onlineYamaha A100 specifications
| Rated output (stereo) | 50W + 50W (stereo, 1% THD, 8 Ohm) |
|---|---|
| Rated output (monaural) | 100W (BTL mono, 1% THD, 16 Ohm) |
| Frequency response | 20 Hz — 20 kHz (0 + 0.5 dB) |
| Total harmonic distortion | 0.02% (1 kHz, 25W/8 Ohm, stereo) |
| Signal to noise ratio | 105 dB (input shorted, IHF A) |
| Dimensions | 220 x 96 x 296 mm |
| Weight | 4.6 kg (10 Ibs. 2 oz) |
All Yamaha A100 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the rated output of the Yamaha A100 in stereo mode?
The rated output is 50W + 50W into 8 Ohms at 1% THD.
How do I connect the amplifier for monaural operation?
Set the MODE switch to MONO and connect the speaker's (+) terminal to CH A and the (-) terminal to CH B.
What type of floppy disks are compatible with this instrument?
The PSR-A1000 accepts both 3.5" 2DD and 2HD type floppy disks.
How often should the disk drive read/write head be cleaned?
Yamaha recommends cleaning the head about once a month to maintain optimum working order.
What type of floppy disks are compatible with this instrument?
The PSR-A1000 accepts both 3.5" 2DD and 2HD type floppy disks.
How often should the disk drive read/write head be cleaned?
Yamaha recommends cleaning the head about once a month to maintain optimum working order.
