Key facts
- Brand
- Yamaha
- Model
- R-2000
- Category
- Audio Power Amplifier
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-13
Start here
Yamaha R-2000 Stereo Receiver Owner's Manual
This document is the owner's manual for the Yamaha R-2000 AM/FM stereo receiver. It provides essential safety warnings regarding moisture, ventilation, and power sources before operating the appliance.
The guide details how to connect external components such as turntables, tape decks, antennas, and speakers. It includes specific instructions on speaker impedance matching and wiring polarity to ensure proper sound quality.
Yamaha R-2000 specifications
| Output Power (HR-2000B) | 30Wr.m.s. (8 ohms, T.H.D.10%) |
|---|---|
| Output Power (HR-3000B) | 50Wr.m.s. (8 ohms, T.H.D.10%) |
| Speaker Size | 25cm x 30cm x 1 |
| Input Jack (HR-2000B) | INPUT (HIGH GAIN) x 1 |
| Power Requirements (General model) | 110V/120V/220V/240V AC,50/60Hz |
| Weight (HR-3000B) | 12.6kg (27lbs. 12o0zs.) |
All Yamaha R-2000 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the recommended speaker impedance for a single pair?
If only one pair is connected, the recommended speaker impedance may be anywhere between 4 and 16 ohms.
Can two pairs of speakers be connected?
Yes, but it is advisable to use speakers with at least an 8 ohm impedance for optimum performance.
What happens if I plug in the amplifier before the guitar?
Plugging in the amplifier first may cause damage to the speaker.
How do I turn off the compressor effect on the HR-3000B?
Set the COMPRESSOR control to the 'OFF' position until it clicks into place.
