Key facts
- Brand
- Yamaha
- Model
- DP100
- Industry
- Appliances
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-12
Start here
YAMAHA PDP-1000 Manual
This document is the Owner's Manual for the Yamaha PDP-100 Personal Digital Piano. It details the features of the instrument, including the AWM tone generator system with 128 voices, 28-note polyphony, and touch-sensitive keys. The guide explains how to use various performance modes such as Split, Solo Styleplay, and Performance Memory.
Read onlineYamaha DP100 specifications
| Input terminals | RCA pin jacks (CH A,B), phone jacks (CH A,B) |
|---|---|
| Input level | -20 dB/-10 dB switchable |
| Input impedance | 10 kOhm |
| Output terminals | RCA pin jacks (CH A,B), phone jacks (CH A,B) |
| Output level | -20 dB/-10 dB switchable |
| Output impedance | 600 Ohm |
| Gate level adjusting range | -60 dB to -70 dB (at -20 dB) |
| Threshold level adjusting range | -4 dB to -44 dB (at -20 dB) |
| Power Supply | DC +12 V |
| Dimensions | 220 x 45.5 x 217 mm |
| Weight | 1.1 kg |
All Yamaha DP100 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What power supply is required for the DP100?
The unit requires a DC +12 V power supply, using only the Yamaha AC adaptor PA-1B or PA-S or the power supply PW100.
Can the limiter and noise gate be used separately?
No, because the DEFEAT switch applies to both channels simultaneously; you cannot switch effects ON/OFF separately for one channel.
What is the maximum polyphony of the PDP-100?
The maximum polyphony is 28 notes.
From: YAMAHA PDP-1000 Manual
How many voices does the PDP-100 have?
It has 128 rich, realistic voices plus a DRUMS voice.
From: YAMAHA PDP-1000 Manual
