Siemens 3VF Molded Case Circuit Breaker Product Sample
This document is a product sample for Siemens 3VF molded case circuit breakers, covering various series including 3VF2, 3VF3, 3VF5, and 3VF6. It details the product's exploded views, descriptions, and application-specific categories such as plant protection, motor protection, and starter combinations.
The sample includes comprehensive selection and ordering data, technical specifications, characteristic curves, circuit diagrams, and dimensional drawings. It also lists a wide range of accessories and spare parts, including auxiliary switches, drive mechanisms, and retrofitting components. This manual is written in Chinese.
Siemens 3VF specifications
| Maximum rated current | 80 A |
|---|---|
| Rated operational voltage | 690 V |
| Rated frequency | 50/60 Hz |
| Mechanical endurance (operating cycles) | 100 000 cycles |
Source: Siemens 3VU13/3VU16/3VF1 Circuit Breaker Product Leaflet
All Siemens 3VF documents by type
Questions answered in these manuals
What is the maximum current rating for 3VF2 circuit-breakers?
The 3VF2 circuit-breakers are rated for up to 100 A.
From: Siemens 3VF Molded Case Circuit Breaker Product Sample
What is the maximum current rating for 3VF3 to 3VF8 circuit-breakers used as switch disconnectors?
These non-automatic circuit-breakers are rated for up to 2000 A.
From: Siemens 3VF Molded Case Circuit Breaker Product Sample
What is the maximum rated current for the 3VU13 circuit‑breaker?
The 3VU13 circuit‑breaker is rated up to 25 A.
From: Siemens 3VU13/3VU16/3VF1 Circuit Breaker Product Leaflet
Do the 3VU16 and 3VF1 circuit‑breakers include overload releases?
The 3VU16 and 3VF1 used in starter combinations have only instantaneous short‑circuit releases and no overload releases.
From: Siemens 3VU13/3VU16/3VF1 Circuit Breaker Product Leaflet
