Siemens SINAMICS G120XA Vector Converter Fan and Pump Application Brochure
The Siemens SINAMICS G120XA is a new member of the SINAMICS series, designed specifically for fan and pump applications with power ranging from 0.75 kW to 560 kW. It integrates advanced vector control algorithms and industry-specific functions such as built-in fans and pumps, allowing for quick setup and efficient operation. This manual is written in Chinese.
Read onlineSiemens SINAMICS G120XA specifications
| Power Range | 0.75 kW ~ 560 kW |
|---|---|
| Input Voltage (FSA...FSG) | 3 AC 380 V (-20 %) ... 440 V (+10 %) |
| Input Voltage (FSH/FSJ) | 3 AC 380 V (-15 %) ... 440 V (+10 %) |
| Operating Temperature (FSA...FSG) | -20 ºC ~ 60 ºC |
| Operating Temperature (FSH/FSJ) | 0 ºC ~ 50 ºC |
| Digital Inputs | 6 channels |
| Digital Outputs | 4 relay outputs, 250V AC 1A / 30V DC 1A |
| Analog Inputs | 2 channels (-10 V ~ 10 V ; 0/4 ~ 20 mA) |
| Analog Outputs | 2 channels (0 V ~ 10 V ; 0/4 ~ 20 mA) |
| Protection Class | IP20, IP00 (FSJ size only) |
Source: Siemens SINAMICS G120XA Vector Converter Fan and Pump Application Brochure
All Siemens SINAMICS G120XA documents by type
Questions answered in these manuals
What applications is the SINAMICS G120XA designed for?
It is specifically designed for fan and pump loads, including water treatment, heating networks, oil/gas/chemical industries, sewage treatment, subway ventilation, and HVAC.
From: Siemens SINAMICS G120XA Vector Converter Fan and Pump Application Brochure
Does the SINAMICS G120XA support specific motor types?
Yes, it supports induction motors, permanent magnet synchronous motors, and reluctance motors with high energy efficiency.
From: Siemens SINAMICS G120XA Vector Converter Fan and Pump Application Brochure
What power range does the SINAMICS G120XA cover?
The product covers a power range from 0.75 kW to 560 kW.
From: Siemens SINAMICS G120XA Variable Frequency Drive Product Brochure
What specific applications is the SINAMICS G120XA designed for?
It is designed for standard fan and pump applications in infrastructure.
