Key facts
- Brand
- Siemens
- Model
- 1LG0
- Category
- AC Motors
- Industry
- Industrial
- Documents
- 2
- Languages
- ZH
- Last added
- 2026-10-18
Start here
Siemens 1LG0 Low-voltage Motors Product Brochure
Product Leaflet 40 pages · 2.2 MB · ZH
The Siemens 1LG0 series consists of Totally Enclosed Fan Cooled (TEFC) three-phase asynchronous motors with an IP55 protection degree. Designed for continuous duty operation, these motors feature cast iron frames and are available in frame sizes from 80mm to 355mm. They comply with ISO, IEC, and GB standards, offering efficiency classes IE1 and GB 18613 Class 3. This manual is written in Chinese.
Read onlineSiemens 1LG0 specifications
| Frame sizes | 80mm ~ 355mm |
|---|---|
| Rated power range | 0.55kW ~ 315kW at 50Hz |
| Protection degree | IP55 |
| Insulation class | F |
All Siemens 1LG0 documents by type
Product Leaflet 1
Questions answered in these manuals
What is the protection degree of the 1LG0 series motors?
The 1LG0 series motors have a protection degree of IP55.
Which standards do the 1LG0 motors comply with?
They comply with ISO, IEC, and GB standards.
