Start here
Siemens OP7 OP17 Operator Panel Equipment Manual
This equipment manual for the Siemens OP7 and OP17 operator panels covers an overview of the panels, their basic operation, and expanded configurable functions such as online system settings, PLC jobs, and scheduling. It also details the mechanical and electrical installation steps, commissioning procedures, and maintenance information.
Technical specifications, interface assignments, and a comprehensive index are included, making the manual a complete reference for qualified personnel who install, configure, and operate these HMI devices.
Siemens SIMATIC OP7 specifications
| Overall dimensions (OP7) | 144 mm x 180 mm x 42.5 mm |
|---|---|
| Degree of protection (front) | IP65 |
| Degree of protection (rear) | IP20 |
| Weight (OP7) | 0.430 kg |
| Flash memory (OP7) | 128 kbytes |
| Number of display lines | 4 (configurable to 8) |
| Characters per line | 20 (or 40 when 8 lines) |
| Font size | 8 mm (OP7) / 11 mm or 6 mm (OP17, depending on lines) |
All Siemens SIMATIC OP7 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the IP rating of the front panel for the OP7?
The front panel of the OP7 has an IP65 degree of protection.
What are the overall dimensions of the OP7 panel?
The OP7 measures 144 mm × 180 mm × 42.5 mm (W × H × D).
What safety symbols are used in the manual?
A warning triangle indicates personal safety hazards, while other symbols such as “注意” (caution) indicate less severe warnings.
From: Siemens OP 73micro, TP 177micro HMI Operating Instructions
Which PLC can be connected to the OP 73micro device?
The OP 73micro can be connected to a SIMATIC S7 PLC using certified cables.
From: Siemens OP 73micro, TP 177micro HMI Operating Instructions
