Philips MASTER LED 10-50W 12V MR16 Dim Manual
The Philips MASTER LED 10-50W 12V MR16 Dim lamp is designed for use in all MR16 lighting installations with a required 10 mm free‑air space around the housing. It offers a long lifetime of 25,000 hours and is compatible with a wide range of standard 12 VAC halogen electronic transformers as well as most leading‑edge dimmers.
The document includes technical specifications such as voltage, power range, colour temperature options, CRI, and dimmable capability, together with guidance on transformer loading, dimmer compatibility, and recommended application areas like hospitality, retail, and industrial OEM lighting.
Philips MR16 specifications
| Luminous Flux (max) | 780 cd |
|---|---|
| Colour Rendering Index | 100 Ra8 |
| Rated Lifetime (hours) | 4000 hr |
| Maximum Operating Temperature | 350 °C (max) |
| Weight | 30.000 g |
Source: Philips Brilliantline Dichroic 20W GU5.3 MR16 36D 1CT Product Data Sheet
All Philips MR16 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the rated lifetime of the Philips MASTER LED 10-50W 12V MR16 Dim lamp?
The lamp is rated for a lifetime of 25,000 hours.
How many of these LED MR16 lamps can be connected to a 150 W halogen transformer?
A 150 W halogen transformer can support up to three of the 10‑50 W MR16 LED lamps.
How long is the expected lifetime of the bulb?
The rated lifetime is 4000 hours, about 2 years.
From: Philips Brilliantline Dichroic 20W GU5.3 MR16 36D 1CT Product Data Sheet
What is the rated lifetime of the Brilliantline Dichroic lamp?
The lamp is rated for 4000 hours of operation (approximately 2 years).
From: Philips Brilliantline Dichroic 35W GU5.3 12V MR16 36D 1CT Manual
How much light does the lamp emit?
The lamp provides a maximum luminous flux of 1500 cd.
From: Philips Brilliantline Dichroic 35W GU5.3 12V MR16 36D 1CT Manual
