Start here
Philips BDL5585XL LCD Display Quick Start Guide
The guide lists the box contents—including remote control, batteries, power cords, VGA cable, and cable box—and provides a brief safety note about wall‑mounting screws. It also shows the rear connector layout and basic HDMI/Audio connections.
Step‑by‑step instructions cover removing the LCD from its packaging, placing it face‑down, inserting batteries into the remote, connecting power and A/V cables, and mounting the display on a wall using six metric 6 mm screws (not supplied). The guide ends with a note on connecting the display to a PC and registering the product on Philips' website.
Philips BDL5585XL specifications
| Power Supply | AC 100V ~ 240V, 50‑60 Hz |
|---|---|
| Power Consumption (Max) | 250 W |
| Display Dimensions (without stand) | 1215.3 mm × 686.1 mm × 126.3 mm |
| Gross Weight | 39 kg |
| Net Weight | 34 kg |
| Operational Temperature | 0 ~ 40 °C (32 ~ 104 °F) |
| Operational Humidity | 10 ~ 90 % RH (no condensation) |
| Audio Output (RMS) | 12 W (L) + 12 W (R) |
| Audio Output SPL | 82 dB/W/M (160 Hz ~ 13 kHz) |
| Maximum Video Resolution | 1920 × 1080 @ 60 Hz (WUXGA) |
Source: Philips BDL5585XL User Manual
All Philips BDL5585XL documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
What is the recommended operating temperature range for the BDL5585XL display?
The display is designed to operate between 0 °C and 40 °C (32 °F to 104 °F).
What are the dimensions of the display without the stand?
The display measures 1215.3 mm wide, 686.1 mm high, and 126.3 mm deep without the stand.
