Panasonic KX-FT922CN / KX-FT926CN / KX-FT928CN / KX-FT929CN Fax Machine User Manual
This manual guides users through installing the fax machine, connecting power and telephone lines, loading the correct thermal recording paper, and performing a quick start. It also covers safety precautions, control panel layout, and basic programming of date, time, and header information.
Detailed sections describe telephone functions, fax sending and receiving, copy operations, answering‑machine features, programmable functions, troubleshooting tips, and full technical specifications such as supported line type, paper size, scanning resolution, power consumption, and physical dimensions. This manual is written in Chinese.
Panasonic KX-FT928CN specifications
| Supported line | Public switched telephone network |
|---|---|
| Maximum document width | 216 mm |
| Maximum document length | 600 mm |
| Recording paper size | 216 mm × up to 30 m roll |
| Scanning resolution (horizontal) | 8 pels/mm |
| Scanning resolution (vertical) | 3.85 line/mm |
| Standby power consumption | ≈ 3.0 W |
| Transmission power consumption | ≈ 25 W |
| Dimensions (H × W × D) | ≈ 120 mm × 347 mm × 270 mm |
| Weight (KX-FT922 / KX-FT928) | ≈ 2.6 kg |
Source: Panasonic KX-FT922CN / KX-FT926CN / KX-FT928CN / KX-FT929CN Fax Machine User Manual
All Panasonic KX-FT928CN documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What safety steps should I take before cleaning the unit?
Unplug the fax machine, do not use liquid or spray cleaners, and wipe it with a damp cloth only.
From: Panasonic KX-FT922CN / KX-FT926CN / KX-FT928CN / KX-FT929CN Fax Machine User Manual
What is the maximum paper size the fax can handle?
The machine accepts documents up to 216 mm wide and 600 mm long.
From: Panasonic KX-FT922CN / KX-FT926CN / KX-FT928CN / KX-FT929CN Fax Machine User Manual
What should be done with the AC power cord before starting any repair?
The AC power cord must be disconnected before any repair work to prevent electric shock.
From: Panasonic KX-FT928CN-B / KX-FT929CN-B / KX-FT928CN-W / KX-FT929CN-W / KX-FT929CN-S Service Manual
What temperature should be set on the soldering iron for PbF solder?
Use a temperature‑controlled iron set to 370 ± 10 °C when soldering with PbF solder.
From: Panasonic KX-FT928CN-B / KX-FT929CN-B / KX-FT928CN-W / KX-FT929CN-W / KX-FT929CN-S Service Manual
