Microchip PIC32 USB OTG Module Reference Manual
This document is Section 27 of the PIC32 Family Reference Manual, detailing the USB On-The-Go (OTG) module. The module supports USB Full-Speed and Low-Speed Host and Device modes, as well as OTG functionality. Key features include integrated signaling resistors, analog comparators for VBUS monitoring, and an integrated USB transceiver, allowing for a minimum of external components.
Read onlineMICROCHIP PIC32 specifications
| USB Speed Support | Full-Speed and Low-Speed |
|---|---|
| Clock Requirement | 48 MHz |
| Integrated Components | Signaling Resistors, Analog Comparators, Transceiver |
| DMA Requirement | Not required |
All MICROCHIP PIC32 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Does the USB OTG module require the DMA module?
No, the USB OTG module does not require the PIC32 DMA module for its operation.
What clock frequency is required for USB operation?
A 48 MHz clock is required for proper USB operation.
How many chapters does the guide contain?
The guide is divided into six chapters covering features, product family, architecture, tools, demo projects, and technical support.
Which section describes the development tools for PIC32?
Chapter 4, titled “PIC32 用ツール”, gives an overview of the MPLAB IDE, compilers, libraries, and other tools.
