Start here
Microchip PICkit 2 MCU Programmer User Manual
This guide provides an overview of the PICkit 2 MCU programmer, including its USB connection, status LEDs, buttons, programming connector and strap attachment. It also describes the software interface, device configuration, and power options.
The manual walks users through getting started, using In‑Circuit Serial Programming (ICSP), employing the Debug Express feature, troubleshooting common issues, and updating the programmer's firmware. An appendix supplies the full hardware schematic. This manual is written in Chinese.
MICROCHIP PICkit 2 specifications
| USB connector type | mini‑B |
|---|---|
| Kit contents | Programmer, USB cable, starter‑kit CD ROM |
| Push button | Not implemented |
Source: Microchip PICkit 2 Microcontroller Programmer User Guide
All MICROCHIP PICkit 2 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What does the Busy LED indicate?
The Busy LED lights red when the PICkit 2 is performing a function such as programming mode or any operation in progress.
From: Microchip PICkit 2 Microcontroller Programmer User Guide
Can the PICkit 2 be used for production programming?
The PICkit 2 is intended for development programming; for production use Microchip recommends the MPLAB PM3 or other production‑grade programmers.
From: Microchip PICkit 2 Microcontroller Programmer User Guide
How do I update the PICkit 2 firmware?
Use Chapter 6 of the manual, which describes the steps to update the PICkit 2 programmer’s operating system.
Where can I find the hardware schematic for the PICkit 2?
The full schematic is provided in Appendix A of the manual.
What does the Busy LED indicate?
The Busy LED (red) shows that the PICkit 2 is processing a function, such as being in programming mode.
From: MICROCHIP pickittm2 microcontroller programming user manual
Can PICkit 2 be used for production programming?
No, for production programming you should use the MPLAB PM3 programmer or another tool designed for production environments.
From: MICROCHIP pickittm2 microcontroller programming user manual
