Start here
Microchip MCP2030 Demo Kit User Guide
This guide explains how to use the MCP2030 bidirectional communication demo kit. It includes a quick‑start procedure, a description of the system architecture, hardware and firmware overviews, schematic diagrams, PCB layout drawings, and a complete bill of materials.
The document also details power requirements for the transceiver and base‑station units, LED status indicators, communication ranges, and how to test signal strength (RSSI) by moving the transceiver within the base‑station field. This manual is written in Chinese.
Microchip MCP2030 specifications
| Transceiver battery | 3 V NiMH (CR2032) |
|---|---|
| Base‑station power supply | 9 V – 18 V |
| LF command frequency | 125 kHz |
| One‑way communication range | ≈ 20 m |
| Two‑way communication distance | ≈ 2 m |
All Microchip MCP2030 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
How do you power the wireless transceiver unit?
Insert a 3 V NiMH (CR2032) battery into the battery holder at the bottom of the transceiver unit.
What power source is required for the base‑station unit?
Connect a power supply of 9 V to 18 V to the base‑station unit.
How many analog input channels does the MCP2030 provide?
The MCP2030 provides three independent low‑frequency analog input channels.
What output options are available on the MCP2030?
The device can output demodulated data, a carrier clock, or an RSSI current.
