Microchip PIC24FJ64GA004 User Manual
The PIC24FJ64GA004 is a 16‑bit flash microcontroller offering up to 16 MIPS CPU performance, 2.0 V‑3.6 V operating voltage, and on‑chip peripherals such as a 13‑channel 10‑bit ADC, enhanced USART, PWM, real‑time clock/calendar, and an on‑chip LDO regulator. It supports multiple power‑saving modes and JTAG boundary‑scan for development.
The manual includes detailed pin‑out tables for 28‑pin PDIP/SOIC, 44‑pin QFN and TQFP packages, electrical characteristics, memory organization (up to 12 MB flash and 64 KB RAM), and usage guidelines for the device’s peripherals and programming interfaces. This manual is written in Chinese.
MICROCHIP PIC24FJ64GA004 specifications
| CPU speed | 16 MIPS |
|---|---|
| Operating voltage | 2.0 V to 3.6 V |
| Flash program memory | up to 12 MB |
| Data RAM | up to 64 KB |
| ADC channels | 13 channels, 10‑bit, 500 ksps |
| Internal oscillator | 8 MHz with 4× PLL |
| On‑chip LDO regulator | present |
| JTAG support | boundary‑scan supported |
| Real‑Time Clock/Calendar | time, date, week functions |
| PWM resolution | 16‑bit |
All MICROCHIP PIC24FJ64GA004 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the operating voltage range of the PIC24FJ64GA004?
The device operates from 2.0 V up to 3.6 V.
How much flash program memory does the PIC24FJ64GA004 provide?
It can hold up to 12 MB of flash program memory.
