MICROCHIP MCP2150 Manuals

ManualLib has 4 documents for the MICROCHIP MCP2150: 2 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 2

Key facts

Model
MCP2150
Industry
Industrial
Documents
4
Languages
ZH · EN
Last added
2023-02-06

Start here

Microchip MCP2120/MCP2150 Developer Kit User Manual

Microchip MCP2120/MCP2150 Developer Kit User Manual

User Manual 64 pages · 2.5 MB · EN

This guide introduces the MCP2120/MCP2150 Developer Kit, lists the kit contents, and references related documentation. It describes the two developer boards, their hardware features, and the system configurations that can be used for infrared communication demonstrations.

The manual includes step‑by‑step tutorials for both the MCP2120 and MCP2150 boards, instructions for using PICDEM 1 or PICDEM 2 boards as host controllers, and detailed hardware descriptions with schematics and jumper settings.

Read online

MICROCHIP MCP2150 specifications

Clock Frequency11.0592 MHz
Max Data Rate (UART)115.2 kbaud
Low Power Current< 1mA @ 3.3V
Standby Current3µA @ 5.0V

Source: Microchip MCP2150 IrDA Controller Datasheet

All MICROCHIP MCP2150 documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Datasheet 2

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What IrDA standards does the MCP2150 support?

It supports IrLAP, IrLMP, IrAS, TinyTP, and IrCOMM (9-line cooked service level).

From: Microchip MCP2150 IrDA Controller Datasheet

What are the supported UART baud rates?

The device supports 9.6 kbaud, 19.2 kbaud, 57.6 kbaud, and 115.2 kbaud.

From: Microchip MCP2150 IrDA Controller Datasheet

What components are included in the MCP2120/MCP2150 Developer Kit?

The kit includes two MCP2120 developer boards, one MCP2150 developer board, two serial cables, a 9 V power supply with cord, a pair of 18‑inch power jumper cables, a sample kit with one MCP2120 device and one MCP2150 device, and the user guide.

From: Microchip MCP2120/MCP2150 Developer Kit User Manual

What baud rates does the MCP2150 support?

The MCP2150 supports UART baud rates of 9.6, 19.2, 57.6 and 115.2 kbaud, and infrared baud rates of 9.6, 19.2, 38.4, 57.6 and 115.2 kbaud.

From: Microchip MCP2150 IrDA Protocol Stack Controller User Manual

Which pins select the serial baud rate?

The serial baud rate is selected by the state of the BAUD1 and BAUDO pins.

From: Microchip MCP2150 IrDA Protocol Stack Controller User Manual

What IrDA standards does the MCP2150 support?

It supports IrLAP, IrLMP, IrAS, TinyTP, and IrCOMM (9-line cooked service level).

From: Microchip MCP2150 IrDA Controller Datasheet
