Analog Devices AD8605/AD8606/AD8608 Operational Amplifier Handbook
The AD8605 (single), AD8606 (dual) and AD8608 (quad) are precision CMOS operational amplifiers featuring ultra‑low offset voltage, low input bias current, low noise and a wide 10 MHz unity‑gain bandwidth. They support single‑supply operation from 2.7 V to 5.5 V and are available in several compact surface‑mount packages.
The document provides detailed electrical specifications, absolute maximum ratings, noise performance data, power‑supply rejection characteristics, dynamic performance figures, pin‑configuration diagrams and an ordering guide for the various package options.
Analog Devices AD8606 specifications
| Low offset voltage | 65 pV max |
|---|---|
| Low input bias current | 1 pA max |
| Low noise | 8 nV/√Hz |
| Unity‑gain bandwidth | 10 MHz |
| Supply voltage range | 2.7 V to 5.5 V |
Source: Analog Devices AD8605/AD8606/AD8608 Operational Amplifier Handbook
All Analog Devices AD8606 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What supply voltage range do the AD8605/AD8606/AD8608 support?
They operate from 2.7 V up to 5.5 V on a single supply.
From: Analog Devices AD8605/AD8606/AD8608 Operational Amplifier Handbook
What is the typical offset voltage of these amplifiers?
The offset voltage is specified as low as 65 pV maximum.
From: Analog Devices AD8605/AD8606/AD8608 Operational Amplifier Handbook
What supply voltage range does the AD8606 support?
The AD8606 operates from a single supply of 2.7 V to 5.5 V.
From: Analog Devices AD8605/AD8606/AD8608 Operational Amplifier Datasheet
What is the unity‑gain bandwidth of the AD8605/AD8606/AD8608 at a 5 V supply?
The unity‑gain bandwidth is 10 MHz.
From: Analog Devices AD8605/AD8606/AD8608 Operational Amplifier Datasheet
