Yamaha 02R Digital Mixing Console User Manual
The Yamaha 02R is a 24‑channel digital mixing console with a central 320 × 240 pixel LCD, motorized faders and extensive digital effects. The manual details the console’s input and output routing, scene memory, EQ and dynamics processing, and provides step‑by‑step operating instructions.
Key sections cover technical specifications, front‑panel layout, display functions, fader status, scene configuration, EQ programming and auxiliary routing, helping users set up and operate the console efficiently. This manual is written in Chinese.
Yamaha 02R specifications
| 输入通道 | 24 路（模拟 24 路 + 数码 16 路） |
|---|---|
| 输出通道 | 8 路母线输出 + 8 路辅助输出 |
| 显示屏分辨率 | 320 × 240 像素 |
| 推子数量 | 21 个 100 mm 电动式推子 |
| 尺寸 | 662.7 mm × 221.5 mm × 685 mm (宽 × 深 × 高) |
| 重量 | 30 kg |
| 动态范围 | 192 dB (32 bit) |
| AD 转换器噪声 | -128 dB (20 Hz‑20 kHz) |
All Yamaha 02R documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- YAMAHA 02R OWNER'S MANUAL(1)(1)
- YAMAHA 02R OWNER'S MANUAL(1)
- YAMAHA DM2000/02R Installation Guide
- YAMAHA Studio Manager for 02R 96 OWNER'S MANUAL
- YAMAHA 02R96 VCM OWNER'S MANUAL
- YAMAHA MB02R96 Editor OWNER'S MANUAL
- YAMAHA ME02R96 OWNER'S MANUAL
- YAMAHA SP02R96 Manual
- YAMAHA 02R96/01V96 OWNER'S MANUAL
- YAMAHA PM5D(RH) M7CL LS9 DM2000 DM1000 02R96 01V96 Manual
Questions answered in these manuals
How many input channels does the Yamaha 02R have?
The console provides 24 input channels, consisting of 24 analog inputs and 16 digital inputs.
What type of display screen is used on the 02R console?
It uses a 320 × 240 pixel LCD graphic display with adjustable contrast and brightness.
