Start here
National Semiconductor 54ACTQ08 Quad 2-Input AND Gate Datasheet
This document is a datasheet for the National Semiconductor 54ACTQ08, a member of the Quiet Series featuring four 2-input AND gates. It utilizes Improved latch-up immunity technology and GTO output control to ensure quiet switching and improved dynamic threshold performance. The device is TTL-compatible and includes a split ground bus for superior AC MOS performance.
Read onlineNational Semiconductor 54AC specifications
| Supply Voltage | 4.5V to 5.5V |
|---|---|
| Operating Temperature | -55°C to +125°C |
| Output Source/Sink Current | 24 mA |
| Input Capacitance | 45 pF |
Source: National Semiconductor 54ACTQ08 Quad 2-Input AND Gate Datasheet
All National Semiconductor 54AC documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- National Semiconductor 54ACTQ08 Quad 2-Input AND Gate Datasheet 5 p
- National Semiconductor 54ACQ240/54ACTQ240 Quiet Series Octal Buffer/Line Driver Datasheet 8 p
- National Semiconductor 54AC/74AC125 and 74ACT125 Quad Buffer Datasheet 9 p
- National Semiconductor MV54ACT257-X REV 0A0 handbook 7 p
- National Semiconductor 54AC/74AC241 54ACT/74ACT241 handbook 4 p
- National Semiconductor 54AC/74AC378 Parallel D Register with Enable Datasheet 8 p
- National Semiconductor 54ACTQ32 Quad 2-Input OR Gate Datasheet 6 p
- National Semiconductor 54ACTQ/74ACTQ02 Quad 2-Input NOR Gate Datasheet 8 p
- National LM1882-54ACT715 LM1882-R-54ACT715-R DATA SHEET(1)(1) 16 p
- National LM1882-54ACT715 LM1882-R-54ACT715-R DATA SHEET(1) 16 p
Questions answered in these manuals
What is the maximum supply voltage for the 54ACTQ08?
The maximum supply voltage is +7.0V.
From: National Semiconductor 54ACTQ08 Quad 2-Input AND Gate Datasheet
What is the minimum input edge rate required for the device?
The minimum input edge rate is 125 mV/ns.
From: National Semiconductor 54ACTQ08 Quad 2-Input AND Gate Datasheet
What is the primary application of the 54ACQ240/54ACTQ240?
They are designed to be employed as a memory address driver, clock driver, and bus oriented transmitter or receiver.
From: National Semiconductor 54ACQ240/54ACTQ240 Quiet Series Octal Buffer/Line Driver Datasheet
What technology does this device use for quiet output switching?
The device utilizes NSC Quiet Series technology to guarantee quiet output switching and improve dynamic threshold performance.
From: National Semiconductor 54ACQ240/54ACTQ240 Quiet Series Octal Buffer/Line Driver Datasheet
What is the function of the 74AC/ACT125?
The device contains four independent non-inverting buffers with TRI-STATE outputs.
From: National Semiconductor 54AC/74AC125 and 74ACT125 Quad Buffer Datasheet
Is the 74ACT125 TTL-compatible?
Yes, the 74ACT125 family has TTL-compatible outputs.
From: National Semiconductor 54AC/74AC125 and 74ACT125 Quad Buffer Datasheet
