The 54ACQ240 is an inverting octal buffer and line driver designed to be employed as a memory address driver, clock driver, and bus-oriented transmitter or receiver, providing improved PC board density. It utilizes NSC Quiet Series technology to guarantee quiet output switching and improve dynamic threshold performance.
The 54ACQ240 and 54ACTQ240 are inverting octal buffers and line drivers designed for use as memory address drivers, clock drivers, and bus-oriented transmitters or receivers. These devices utilize National Semiconductor's Quiet Series technology to ensure quiet output switching and improved dynamic threshold performance.
| Supply Voltage (VCC) - ACQ | 2.0V to 6.0V |
|---|---|
| Supply Voltage (VCC) - ACTQ | 4.5V to 5.5V |
| Operating Temperature | -55°C to +125°C |
| Output Source/Sink Current | 24 mA |
| ESD Immunity | 4 kV minimum |
| Maximum Input Leakage Current | ±1.0 µA |
| Maximum Quiescent Supply Current | 80.0 µA |
They are designed to be employed as a memory address driver, clock driver, and bus oriented transmitter or receiver.
The device utilizes NSC Quiet Series technology to guarantee quiet output switching and improve dynamic threshold performance.
The output enable inputs are labeled OE1 and OE2.
