National Semiconductor LM1086 Low Dropout Voltage Regulator Datasheet
The document is a technical datasheet for the LM1086, a three-terminal low dropout voltage regulator capable of delivering up to 1.5A of output current. It supports both adjustable and fixed output voltages in SOT-223 and TO-263 (D2) packages.
Read onlineNational Semiconductor LM1086 specifications
| Output Current | 1.5A |
|---|---|
| Dropout Voltage | 500mV at 1.5A |
| Line Regulation | 0.015% |
| Load Regulation | 0.1% |
| Supply Voltage (Max) | 7V |
| Operating Junction Temperature Range | -65 to +125 C |
| Thermal Resistance (Junction to Ambient) | 60 C/W |
Source: National Semiconductor LM1086 Low Dropout Voltage Regulator Datasheet
All National Semiconductor LM1086 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What are the available output voltage options?
The device offers fixed outputs of 1.5V, 2.5V, 2.85V, 3.0V, 3.3V, and 5.0V, as well as an adjustable version.
From: National Semiconductor LM1086 Low Dropout Voltage Regulator Datasheet
What packages are available for the LM1086?
The regulator is available in SOT-223 and TO-263 (D2 Package) surface mount options.
From: National Semiconductor LM1086 Low Dropout Voltage Regulator Datasheet
What are the available fixed output voltages?
Fixed versions are available in 1.8V, 2.5V, 2.85V, 3.3V, 3.45V, and 5.0V.
From: National Semiconductor LM1086 Low Dropout Positive Regulator Datasheet
What packages are the LM1086 available in?
The series is available in TO-220, TO-263, and LLP packages.
From: National Semiconductor LM1086 Low Dropout Positive Regulator Datasheet
