Start here
MOTOROLA MOTOROLA GP350 User Guide User Guide
This guide begins with safety and regulatory information, covering essential precautions such as keeping ventilation openings clear, maintaining a minimum two‑inch clearance from surrounding surfaces, and avoiding heat sources during installation. It also outlines the required power supply (Motorola part number 524475‑034 for North American models) and details the FCC Class B compliance requirements.
The manual then describes the front and rear panel layout, basic operation (power on/off, channel changes, volume control), and the interactive program guide. Comprehensive connection instructions cover HDMI, IEEE‑1394, component video, composite video, and audio setups for HDTV, SDTV, and A/V receivers, as well as wall‑mounting procedures with specific screw and clearance specifications.
Motorola GP350 specifications
| Required power supply (North America) | Motorola part number 524475‑034 |
|---|---|
| Mounting screw size | M3.5 × 38 mm (#6 × 1½ in) with max head diameter 9.0 mm |
| Minimum hole depth for wall mounting | 1½ inches (8.8 cm) |
| Clearance between wall and screw head | 0.10 inches (2.5 mm) |
| Maximum ambient temperature during operation | 40 °C (104 °F) |
| FCC classification | Class B digital device |
All Motorola GP350 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
Who is the intended audience for the GP350 Service Manual?
The manual is intended for experienced technicians familiar with similar equipment.
How can I obtain technical support for the GP350 portable radio?
Technical support can be obtained by calling Motorola’s Radius Product Services at the numbers listed in the manual.
What power supply part number is required for the DCX700 North American model?
You must use a Motorola power supply with part number 524475‑034.
