Canon HR10 A HD Camcorder Instruction Manual
This manual covers safety warnings, setup, and basic operation of the Canon HR10 A camcorder, including power connection, battery charging, menu navigation, and recording settings. It explains the three supported 8 cm mini DVD disc types (DVD‑R, DVD‑R DL, DVD‑RW) and how to select image quality (HD or SD) and disc specifications.
The document also lists the camcorder's technical specifications such as recording system, video and audio compression, sensor details, and maximum recording times. Warranty information and service instructions are provided at the end of the guide.
Canon HR10 specifications
| Recording System | AVCHD (all disc types) |
|---|---|
| Video Compression | MPEG‑4 AVC/H.264 |
| Audio Compression | Dolby Digital 2‑ch |
| Television System | 1080/60i NTSC |
| Compatible Media | 8 cm mini DVD discs (DVD‑R, DVD‑R DL, DVD‑RW) |
| Maximum Recording Time (single‑layer) | 15‑33 min (varies by mode) |
| Image Sensor | 1/2.7‑inch CMOS, approx. 2.96 MP |
| LCD Screen | 2.7 in. TFT color, approx. 211 k pixels |
| Lens | f=6.1‑61 mm, F/1.8‑3.0, 10× zoom |
All Canon HR10 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How can I avoid electric shock when using the camcorder?
Do not expose the camcorder to rain or moisture, use only recommended accessories, and follow the safety warnings in the manual.
How do I record in high‑definition versus standard‑definition?
Select HD quality for 1080‑line video using AVCHD‑compatible discs, or choose SD quality for standard‑definition MPEG‑2 video.
What is the maximum video resolution of the HR10?
The camcorder can record in HD 1080 resolution (1920×1080).
