Key facts
- Brand
- Yamaha
- Model
- MX200
- Category
- Other
- Industry
- Electronics
- Documents
- 4
- Languages
- JA
- Last added
- 2012-07-02
Start here
Yamaha EMX2000 Powered Mixer User Manual
This manual explains safe handling, installation, and proper use of the Yamaha EMX2000 powered mixer. It covers power requirements, speaker and input connections, control panel functions, and digital effect selection.
Additional sections describe basic operation, system setup for band PA or conference sound, sub‑woofer usage, and service information including warranty and repair procedures. This manual is written in Japanese.
Yamaha MX200 specifications
| Input Channels | 8 (MX200-8), 12 (MX200-12), 16 (MX200-16), 24 (MX200-24) |
|---|---|
| Power Supply | AC100V, 50/60 Hz |
| Input Connectors | INPUT A: XLR, INPUT B: balanced phone |
All Yamaha MX200 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many input channels does each MX200 model have?
The MX200‑8 has 8 channels, the MX200‑12 has 12, the MX200‑16 has 16, and the MX200‑24 has 24 input channels.
What voltage and frequency should be used to power the MX200?
Connect the console to an AC100 V mains supply, either 50 Hz or 60 Hz.
What voltage should be used with the EMX2000?
The unit is designed for AC 100 V only; other voltages must not be used.
How many input channels does the EMX2000 have?
It provides eight mono inputs, two stereo inputs, and two stereo‑sub inputs.
