STMicroelectronics STM32F0DISCOVERY Manuals

ManualLib has 4 documents for the STMicroelectronics STM32F0DISCOVERY (microcontrollers): 2 user manuals, 1 product leaflet, 1 application note. Every file can be read online or downloaded as a PDF for free.

User Manual 2Product Leaflet 1Application Note 1

Key facts

Model
STM32F0DISCOVERY
Documents
4
Languages
EN
Last added
2023-10-27

Start here

UM1525 User manual

UM1525 User manual

User Manual 41 pages · 2.4 MB · EN

The STM32F0DISCOVERY is a low-cost evaluation board designed to help users quickly evaluate and develop applications for the STM32 F0 series Cortex-M0 microcontrollers. The kit includes an on-board ST-LINK/V2 debug tool, LEDs, push buttons, and a prototyping board.

Read online

STMicroelectronics STM32F0DISCOVERY specifications

MicrocontrollerSTM32F051R8T6
Flash Memory64 KB
RAM8 KB
Clock Speedup to 48 MHz
Supply Voltage1.8/2.0 to 3.6 V
Debug ToolST-LINK/V2
LEDs4
Buttons2
Power OptionsUSB or external 5V

Source: STMicroelectronics STM32F0DISCOVERY Discovery kit User Manual

All STMicroelectronics STM32F0DISCOVERY documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Application Note 1

How to use the product for one specific task, with worked examples.

Questions answered in these manuals

How do I power the STM32F0DISCOVERY?

It can be powered through USB or from an external 5V supply.

From: STMicroelectronics STM32F0DISCOVERY Discovery kit User Manual

What is the microcontroller used in the STM32F0DISCOVERY?

It uses the STM32F051R8T6 microcontroller with 64 KB Flash and 8 KB RAM.

From: STMicroelectronics STM32F0DISCOVERY Discovery kit User Manual

What is the order code for the STM32F0 Discovery kit?

The order code to use is STM32F0DISCOVERY.

From: UM1525 User manual

Which operating systems are supported for this development kit?

The system requirements include Windows PC versions XP, Vista, and 7.

From: UM1525 User manual

What is the STM32F0DISCOVERY kit based on?

The kit is based on the STM32F051R8T6 microcontroller.

From: STMicroelectronics STM32F0DISCOVERY Kit Data Brief

How can the STM32F0DISCOVERY kit be powered?

The kit can be powered through USB bus or from an external 5 V supply voltage.

From: STMicroelectronics STM32F0DISCOVERY Kit Data Brief
