STMicroelectronics STM32F4DISCOVERY Manuals

ManualLib has 4 documents for the STMicroelectronics STM32F4DISCOVERY (microcontrollers): 1 user manual, 1 product leaflet, 2 application notes. Every file can be read online or downloaded as a PDF for free.

User Manual 1Product Leaflet 1Application Note 2

Key facts

Model
STM32F4DISCOVERY
Documents
4
Languages
EN
Last added
2023-10-20

Start here

STMicroelectronics STM32F4DISCOVERY User Manual

STMicroelectronics STM32F4DISCOVERY User Manual

User Manual 46 pages · 1.7 MB · EN

This user manual guides developers through setting up and using the STM32F4DISCOVERY board. It covers system requirements, running built-in demonstrations, and using various toolchains like IAR, Keil, Atollic TrueSTUDIO, and TASKING. The manual includes details on firmware packages, libraries, and binary images for reprogramming. It also provides instructions for hardware connections and debugging.

The document is structured to help beginners build and run sample applications, as well as create their own projects using the provided libraries and examples.

Read online

All STMicroelectronics STM32F4DISCOVERY documents by type

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Application Note 2

How to use the product for one specific task, with worked examples.

Questions answered in these manuals

What cables are needed to power the STM32F4DISCOVERY board and connect to the ST-LINK/V2?

A 'USB type A to Mini-B' cable is used to power the board and connect to the ST-LINK/V2.

From: STMicroelectronics STM32F4DISCOVERY User Manual

What is required to run the built-in demonstration on the STM32F4DISCOVERY board?

The board must have jumper JP1 on and CN3 on, and be connected via a 'USB type A to Mini-B' cable.

From: STMicroelectronics STM32F4DISCOVERY User Manual

What power supplies can be used for the board?

The board can receive power through a USB bus or from an external 5 V supply voltage.

From: STMicroelectronics STM32F4DISCOVERY Discovery Board Data Brief

What is the maximum storage capacity of the microcontroller?

The STM32F407VGT6 microcontroller features 1 MB Flash.

From: STMicroelectronics STM32F4DISCOVERY Discovery Board Data Brief

What communication protocol is used for the firmware upgrade example?

The example uses USB Host mass storage.

From: STMicroelectronics AN3990 Firmware Upgrade Application Note

Is a host computer required to perform the firmware upgrade?

No, the user only needs a Flash disk to upgrade the target STM32 device.

From: STMicroelectronics AN3990 Firmware Upgrade Application Note
