Maxim MAX3316-MAX3319 RS-232-Compatible Transceivers Datasheet
The MAX3316‑MAX3319 family are low‑dropout RS‑232‑compatible transceivers that operate from +2.25 V to +3.0 V and support data rates up to 460 kbps. They include Maxim’s AutoShutdown Plus feature, which reduces supply current to micro‑amp levels when the RS‑232 cable is disconnected or idle for more than 30 seconds, and a READY logic output indicating charge‑pump status.
These devices are offered in space‑saving 16‑pin SSOP and 20‑pin TSSOP packages (MAX3316) and 20‑pin SSOP/TSSOP for the other variants. Typical applications include palmtop computers, handheld instruments, pagers, cellular phones, GPS units, and other portable electronics. The datasheet contains absolute maximum ratings, electrical and timing characteristics, pin descriptions, and example application circuits.
Maxim RS-232-COMPATIBLE specifications
| Supply Voltage Range | +2.25 V to +3.0 V |
|---|---|
| Maximum Data Rate | 460 kbps |
| Operating Temperature Range | -40 °C to +85 °C |
| Package Options | 16‑pin SSOP, 20‑pin TSSOP (MAX3316); 20‑pin SSOP, 20‑pin TSSOP (MAX3317/8/9) |
Source: Maxim MAX3316-MAX3319 RS-232-Compatible Transceivers Datasheet
All Maxim RS-232-COMPATIBLE documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum data rate of the MAX3316‑MAX3319 transceivers?
They are guaranteed to operate at data rates up to 460 kbps.
From: Maxim MAX3316-MAX3319 RS-232-Compatible Transceivers Datasheet
What package options are available for the MAX3316?
The MAX3316 is offered in 16‑pin SSOP and 20‑pin TSSOP packages.
From: Maxim MAX3316-MAX3319 RS-232-Compatible Transceivers Datasheet
What is the maximum data rate of the MAX3314E?
The MAX3314E guarantees a data rate of up to 460 kbps.
From: Maxim MAX3314E RS-232-Compatible Transceiver Datasheet
How much current does the device draw in shutdown mode?
In shutdown mode the transmitter current is reduced to 1 pA while the receiver remains active.
From: Maxim MAX3314E RS-232-Compatible Transceiver Datasheet
What is the shutdown supply current of the MAX3314?
The shutdown supply current is 1 pA when SHDN is low.
Which package options are offered for the MAX3314?
The MAX3314 is available in 8‑pin SOT23, uMAX, and SO packages.
