HP xw4300 Workstation Manual
The HP xw4300 workstation is a flexible, tool‑free, convertible system designed for engineers, designers, scientists and power users. It supports a range of Intel processors, memory configurations, storage options and graphics solutions, and can be configured as a tower or rack‑mount unit.
The manual details supported operating systems (Windows XP Professional 32/64‑bit and Red Hat Enterprise Linux 64‑bit), hardware specifications such as up to 8 GB DDR2 memory, multiple expansion slots, 460 W power supply, and various audio, video and networking interfaces. This manual is written in Chinese.
HP xw4300 specifications
| Chassis Form Factor | Dual-use (Horizontal or Vertical), Micro Tower |
|---|---|
| Front Side Bus | 1066 MHz |
| Chipset | Intel 955X Express |
| Maximum Memory (ECC) | 8 GB DDR2 533 MHz ECC |
| Maximum Memory (non-ECC) | 1 GB DDR2 533 MHz non-ECC |
| RAID Support | 0/1/5/10 |
| Power Supply | 460 W |
| Weight (Minimum Configuration) | 15 kg (33 lbs) |
| Weight (Maximum Configuration) | 18 kg (40 lbs) |
All HP xw4300 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What types of users is the HP xw4300 Workstation designed for?
The workstation is designed to meet the computing requirements of engineers, designers, scientists, and advanced users.
What is the maximum weight of the highest configuration of the HP xw4300 Workstation?
The highest configuration of the workstation weighs 18 kilograms (40 pounds).
What processors are supported by the HP xw4300 Workstation?
It supports Intel Pentium 4 processors with hyper‑threading (e.g., 660 @ 3.6 GHz) and Intel Pentium D dual‑core processors (e.g., 840 @ 3.2 GHz).
What memory configurations can be installed?
The workstation can be equipped with DDR‑2 PC2‑5300 ECC modules up to 4 GB (4 × 1 GB) or non‑ECC modules ranging from 256 MB to 4 GB.
How many and what type of expansion slots does the workstation provide?
The system provides six expansion slots: one PCIe x16, one PCIe x1, one PCIe x4 (x8 connector) and three standard PCI slots.
What is the power supply rating of the HP xw4300?
The workstation is equipped with a 460 W power supply.
