HP Designjet L25500 Series Site Preparation Guide
This document is the Site Preparation Guide (Second Edition) for the HP Designjet L25500 printer series, covering both 42-inch and 60-inch models. It outlines customer responsibilities regarding site readiness before installation begins.
The guide details physical space requirements, including unloading routes and clearances needed around the machine. It specifies environmental conditions such as temperature, humidity, and ventilation needs to ensure optimal print quality and prevent damage. Additionally, it provides electrical settings for single-phase power lines, circuit breaker specifications, and plug types compatible with various countries and regions. This manual is written in Chinese.
HP Designjet L25500 specifications
| Best print quality relative humidity range | 20–80% |
|---|---|
| Best print quality temperature range | 18 to 25°C (64 to 77°F) |
| Print temperature range | 15 to 30°C (59 to 86°F) |
| Maximum altitude for printing | 3000 meters (10,000 feet) |
| Maximum power consumption (60-inch model) | 4.8 kW |
| Minimum door width for unloading | 40 inches (1.01 meters) |
All HP Designjet L25500 documents by type
Mounting, wiring and first power-up. Read it before the hardware goes in.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
How much time is needed for installation preparation?
At least three hours of installation time should be prepared.
What is the minimum width required for doorways to move the printer?
Doorways must have a minimum width of 40 inches (1.01 meters).
How can printer status information be retrieved via the embedded web server?
Open a web browser, enter the printer’s URL, then select Support → Troubleshooting → Printer Information.
From: HP Designjet L25500 Printer Series Maintenance and Troubleshooting Guide
What should be done if the printer cannot obtain an IP address?
Follow the troubleshooting steps listed under the “Other troubleshooting” section for IP address issues.
From: HP Designjet L25500 Printer Series Maintenance and Troubleshooting Guide
