Fatal1ty Z68 Professional Gen3 Series Motherboard Quick Installation Guide
This Quick Installation Guide introduces the Fatal1ty Z68 Professional Gen3 Series motherboard, a high‑performance ATX board built by ASRock for gamers. It provides an overview of the board’s layout, I/O panel, and key components.
The guide includes detailed specifications, connector descriptions, and step‑by‑step instructions for installing the operating system, configuring BIOS settings, and enabling features such as multi‑streaming audio and UEFI boot on large hard drives.
ASRock Z68 specifications
| Form factor | Micro ATX (9.6" x 9.6", 24.4 cm x 24.4 cm) |
|---|---|
| CPU socket | LGA1155 (supports 2nd‑gen Intel Core i7/i5/i3) |
| Memory slots | 4 DDR3 DIMM slots |
| Maximum memory | 32 GB |
| PCI Express slots | 1 × PCIe 2.0 x16, 2 × PCIe 2.0 x1, 1 × PCI |
| USB 3.0 ports | 2 (front) + 2 (rear) |
| SATA III ports | 2 (6 Gb/s) |
| Network controller | Realtek RTL8111E Gigabit Ethernet |
| Audio codec | Realtek ALC892 |
Source: ASRock Z68 Pro3-M User Manual
