ASRock Z68 Extreme4 Gen3 Motherboard is a ATX specification motherboard from ASRock that supports the second generation Intel Core i7 / i5 / i3 processors, supports DDR3 2133 (overclocked) / 1866 (overclocked) / 1600 / 1333 / 1066 non-ECC, un-buffered memory, and supports a maximum of 32GB system capacity.
The Z68 Extreme4 Gen3 is an Intel Z68 chipset motherboard supporting Intel Core i7, i5 and i3 processors with LGA1155 socket. It offers four DDR3 memory slots, dual PCI‑Express 3.0 x16 slots, and a range of connectivity options including SATA3, USB 3.0, and high‑speed networking.
The manual covers BIOS configuration, the ASRock ExtremeTuning Utility, audio and video settings, RAID options, and software bundles such as CyberLink MediaEspresso. Detailed diagrams illustrate connector layouts, and troubleshooting tips help resolve common issues. This manual is written in Chinese.
| Memory Slots | 4 x DDR3 DIMM |
|---|---|
| PCI Express Slots | 2 x PCIe 3.0 x16, 1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1 |
| Network Controller | Broadcom BCMS7781 10/100/1000 Mb |
| USB 3.0 Ports | 2 (front panel) |
| SATA3 Ports | 2 (Marvell SE9120) |
| RAID Support | RAID 0, 1, 5, 10 on SATA2 ports |
| Maximum Shared Video Memory | 1759 MB |
It provides two USB 3.0 ports on the front panel.
Yes, the SATA2 ports support RAID 0, RAID 1, RAID 5 and RAID 10.
