This motherboard supports 2nd Generation Intel Core i7/i5/i3 processors, adopts 12-inch x 7.5-inch ATX board type, equipped with 4+2 phase power design, supports Intel Turbo Boost 2.0 technology, supports Hyper-Threading technology, and is equipped with a variety of high-end audio and network interfaces
This manual covers the key features of the ASRock Z68 Pro3 Gen3 motherboard, including its ATX form factor, LGA1155 socket for 2nd‑generation Intel Core processors, and support for DDR3 memory up to 32 GB. It details the UEFI BIOS interface, integrated Realtek ALC892 7.1‑channel audio, and networking capabilities such as Gigabit Ethernet with Wake‑On‑LAN.
The document also lists all onboard connectors: multiple USB 3.0 and USB 2.0 ports, SATA3 and SATA2 interfaces, PCI Express slots (1 × PCIe 3.0 x16, 3 × PCIe 2.0 x1), and audio/video outputs (D‑Sub, DVI‑D, HDMI). Installation guidance and quick‑start steps are provided to help users set up the board efficiently. This manual is written in Chinese.
| Form factor | ATX |
|---|---|
| CPU socket | LGA1155 (2nd‑gen Intel Core i7/i5/i3) |
| Memory slots | 4 × DDR3 DIMM, up to 32 GB, 1866 MHz (XMP) |
| SATA ports | 2 × SATA3, 2 × SATA2 |
| USB ports | 4 × USB 2.0, 2 × USB 3.0 |
| Audio codec | Realtek ALC892, 7.1‑channel |
| BIOS | UEFI graphical BIOS with ASRock Extreme Tuning Utility |
It uses an LGA1155 socket that supports 2nd‑generation Intel Core i7, i5, and i3 processors.
The motherboard includes two USB 3.0 ports.
The board features a Realtek ALC892 7.1‑channel audio codec.
Yes, it supports Wake‑On‑LAN networking functionality.
