Start here
ASRock P4VM800Pro-DDR2 Motherboard User Manual
This manual introduces the ASRock P4VM800Pro-DDR2 Micro ATX motherboard and guides users through hardware installation, including CPU, memory, expansion cards, and SATA devices. It also covers BIOS configuration, power‑on diagnostics, and the features of the ASRock I/O Plus™ rear panel.
Later sections describe the support CD contents, driver installation, operating‑system setup for Windows 98/ME/2000/XP, and safety cautions such as over‑clocking limits and RAID configuration. Technical specifications and connector pin‑outs are listed for quick reference.
ASRock P4VM800 specifications
| Form Factor | Micro ATX (9.6" x 8.2") |
|---|---|
| CPU Socket | Socket 478 for Intel Pentium 4 / Celeron D |
| Chipset | VIA P4M800Pro (Northbridge) / VIA VT8237R Plus (Southbridge) |
| Memory Slots | 2 DDRII DIMM slots, up to 2 GB DDRII‑533 |
| Expansion Slots | 3 PCI, 1 AGP (1.5 V 8X/4X), 1 AMR |
| SATA Connectors | 2 × 1.5 Gb/s, supports RAID 0/1/JBOD and Hot‑Plug |
| USB Ports | 6 rear USB 2.0 ports + 2 headers (4 additional ports) |
| LAN | VIA PHY VT6103, 10/100 Mbps Ethernet, Wake‑On‑LAN |
All ASRock P4VM800 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What CPU socket does the P4VM800Pro-DDR2 motherboard use?
It uses a Socket 478 compatible with Intel Pentium 4 and Celeron D processors.
How much memory can the motherboard support?
The board supports up to 2 GB of DDRII‑533 memory across its two DIMM slots.
What is the form factor of the ASRock P4VM800 motherboard?
It is a Micro ATX board measuring 9.6 inches by 8.0 inches.
Which CPUs are supported by the P4VM800?
The board supports Intel Pentium 4 and Celeron processors for Socket 478, including Prescott, Northwood, and Willamette cores.
