Intel Z68 Installation Guide for SATA Hard Disks and RAID Configuration

This document is the user manual of ASUS P8Z68-V PRO motherboard. It introduces the functions and features, installation steps and precautions of the motherboard in detail.

Brand: ASRock
Category: Hard disk
Document type: Installation Guide
Language: English
Pages: 15
File format: PDF
File size: 1.4 MB
Published: 14 March, 2012
Updated: 30 September, 2023
Model: Z68
MD5 checksum: F4B811E2F079CEEB262AD7B8FF7B5ADF
PDF: Intel Z68 Installation Guide for SATA Hard Disks and RAID Configuration PDF

About this manual

The document provides step‑by‑step instructions for installing Serial ATA (SATA) hard disks on a motherboard that uses the Intel Z68 chipset. It covers BIOS settings, driver preparation, and the creation of RAID volumes.

It also details RAID configuration options (RAID 0, 1, 5, 10), precautions, migration from a RAID‑Ready system, and how to delete RAID volumes, with specific procedures for Windows XP, Vista, and Windows 7 installations.

What's inside

Guide to SATA Hard Disks Installation
Guide to RAID Configurations
RAID Configuration Precautions
Installing Windows with RAID Functions
Setting up a RAID Ready System
Migrating a RAID Ready System
Deleting RAID Volume

Specifications

Number of SATA channels	4

Frequently asked questions

How many drives are required for a RAID 5 array?

A minimum of three identical hard disk drives is required for RAID 5.

What BIOS setting must be changed to enable RAID?

Set the “SATA Operation Mode” to [RAID] in the BIOS setup utility.

Can a RAID‑Ready system be migrated to RAID 0?

Yes, you can migrate a RAID‑Ready system to RAID 0 by adding a second drive and using the Intel Storage Utility to create the RAID volume.
