This document describes the features and characteristics of the fastest USB (XFast USB) Intel® Z68 chipset Z68 Extreme3 Gen3.
This manual details the Z68 Extreme 3 Gen3 ATX motherboard, covering CPU support, memory configuration, expansion slots, storage interfaces, and onboard I/O. It also describes the BIOS features, software utilities such as the ASRock Extreme Tuning Utility, and installation accessories.
Key sections include hardware specifications, networking capabilities, audio implementation, power delivery design, and troubleshooting guidance. The document also lists the included accessories and provides a quick‑start guide for first‑time setup. This manual is written in Chinese.
| CPU socket | LGA1155 |
|---|---|
| Memory slots | 4 x DDR3 |
| Maximum memory | 32 GB |
| PCIe x16 slots | 2 (PCIe 3.0/2.0) |
| Network controller | Realtek RTL8111E Gigabit Ethernet |
| Audio codec | Realtek ALC892 |
| Form factor | ATX 12.0" x 8.6" (30.5 cm x 21.8 cm) |
| BIOS | 64 Mb AMI UEFI |
It supports second‑generation Intel Core i7, i5, and i3 processors using the LGA1155 socket.
