Start here
ASRock 775VM800Pro-DDR2 User Manual
This manual covers everything you need to install and configure the ASRock 775VM800Pro-DDR2 motherboard, including package contents, hardware layout, and step‑by‑step installation instructions for CPU, memory, and expansion cards.
It also details BIOS configuration options, software support, and troubleshooting tips, with a full list of specifications such as chipset, memory capacity, and I/O ports.
ASRock 775VM8 specifications
| Form Factor | Micro ATX (9.6" x 8.5") |
|---|---|
| CPU Socket | 775‑Pin LGA socket supporting Intel Dual Core, Pentium D, Pentium 4, Celeron D |
| Chipset | Northbridge VIA P4M800Pro, Southbridge VIA VT8237R Plus |
| Memory | 2 DDRII DIMM slots, DDRII‑533, max 2 GB |
| Audio | Cmedia 5.1‑channel audio codec |
| LAN | VIA PHY VT6103, 10/100 Mb Ethernet, Wake‑On‑LAN |
| SATA Connectors | 2 Serial ATA 1.5 Gb/s connectors (RAID 0,1,JBOD, Hot‑Plug) |
| USB Ports | 6 rear USB 2.0 ports |
All ASRock 775VM8 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What type of CPU socket does the 775VM800Pro-DDR2 motherboard use?
It uses a 775‑Pin LGA socket that supports Intel Dual Core, Pentium D, Pentium 4 and Celeron D processors.
What is the maximum memory capacity supported?
The board can hold up to 2 GB of DDRII‑533 memory.
What CPUs are supported by the ASRock 775VM800 motherboard?
It supports Intel 840EE, Pentium D, Pentium 4 and Celeron D processors in the 775‑Pin socket.
How many USB 2.0 ports does the motherboard provide?
The board provides eight USB 2.0 ports – six on the rear panel and two via an internal header.
Which Windows operating systems are supported by the 775VM8 motherboard?
It supports Microsoft Windows 98 SE, ME, 2000 and XP.
How many USB 2.0 ports does the motherboard provide?
The board provides eight USB 2.0 ports – six on the rear panel and two via on‑board headers.
