ASRock P65iCafe Motherboard User Manual
This manual describes the ASRock P65iCafe ATX motherboard built on the Intel H61 chipset. It supports LGA1155 second‑generation Intel Core i5/i7/i3 CPUs, four DDR3 DIMM slots for up to 16 GB of memory, a 1×PCI‑Express 2.0 ×16 slot, two PCI‑Express 2.0 ×1 slots, and additional PCI slots. The board offers a range of I/O including 6 USB 2.0 ports, HDMI, SPDIF, audio jacks, Gigabit Ethernet, and SATA3/2 connectors.
The BIOS is a 32 MB AMI UEFI implementation with graphical interface and features such as Instant Flash, APP Charger, and THX TruStudio audio support. The manual also lists bundled software like CyberLink MediaEspresso and ASRock Extreme Tuning Utility (AXTU) for hardware monitoring and fan control. This manual is written in Chinese.
ASRock P65ICAFE specifications
| Form factor | ATX 12.0‑in x 8.6‑in (30.5 cm x 21.8 cm) |
|---|---|
| CPU socket | LGA1155, supports 2nd/3rd‑gen Intel Core i7/i5/i3 |
| Memory slots | 4 × DDR3 DIMM slots |
| Maximum memory | 16 GB |
| Chipset | Intel H61 |
| PCI‑Express x16 slot | 1 × PCIe 3.0 x16 (blue) |
| Audio codec | Realtek ALC887, 7.1‑channel HD Audio |
| LAN controller | Realtek RTL8111E Gigabit LAN |
| BIOS | 32 Mb AMI BIOS |
All ASRock P65ICAFE documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
Which Windows versions are required to install on a HDD larger than 2 TB?
You must use Windows Vista 64‑bit (SP1 or later) or Windows 7 64‑bit.
How many DDR3 DIMM slots does the P65iCafe motherboard have?
The motherboard provides four DDR3 DIMM slots.
What CPU socket does the ASRock P65iCafe motherboard use?
It uses an LGA1155 socket for second‑generation Intel Core i5, i7, and i3 processors.
Which audio codec is integrated on the motherboard?
The motherboard uses the Realtek ALC887 audio codec for high‑fidelity sound.
