ASRock IMB-170 Manuals

ManualLib has 3 documents for the ASRock IMB-170 (Motherboard): 1 user manual, 2 datasheets. Every file can be read online or downloaded as a PDF for free.

User Manual 1Datasheet 2

Key facts

Brand
ASRock
Model
IMB-170
Category
Motherboard
Documents
3
Languages
EN
Last added
2023-10-16

Start here

ASRock IMB-170/IMB-170-V Motherboard User Manual

ASRock IMB-170/IMB-170-V Motherboard User Manual

User Manual 58 pages · 1.1 MB · EN

The document serves as a comprehensive user guide for the ASRock IMB-170 and IMB-170-V motherboards. It details package contents, hardware specifications including CPU socket G2 support and DDR3 memory capabilities, and provides step-by-step instructions for installing components such as memory modules, expansion slots, and hard drives.

The guide also covers the UEFI Setup Utility configuration, explaining how to navigate menus for CPU, storage, and security settings. Additionally, it includes specific procedures for operating system installation (Windows XP, Vista, 7) with and without RAID configurations.

Read online

ASRock IMB-170 specifications

Form FactorMini ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
CPU SocketSocket G2(rPGA988B)
ChipsetIntel QM77
Memory Support2 x DDR3 SO-DIMM slots, Max. capacity of 16GB
Graphics OutputDisplayPort, DVI-I (D-Sub Port for IMB-170-V), LVDS and HDMI
LAN Ports2 x PCIE x1 Gigabit LAN 10/100/1000 Mb/s

Source: ASRock IMB-170/IMB-170-V Motherboard User Manual

All ASRock IMB-170 documents by type

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Datasheet 2

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What operating systems are supported by this motherboard?

The motherboard supports Microsoft Windows 7 / 7 64-bit / Vista TM / Vista TM 64-bit / XP / XP 64-bit and is Linux compliant.

From: ASRock IMB-170/IMB-170-V Motherboard User Manual

Does the IMB-170-V model support D-Sub output?

Yes, the IMB-170-V includes a DVI-I Port which functions as a D-Sub Port.

From: ASRock IMB-170/IMB-170-V Motherboard User Manual

What processors does the ASRock IMB-170 support?

It supports Intel Core i7, i5, i3, and Celeron processors based on Ivy Bridge and Sandy Bridge architectures.

From: ASRock IMB-170 Motherboard Datasheet

What is the maximum system memory capacity?

The motherboard supports up to 16GB of system memory using two SO-DIMM slots.

From: ASRock IMB-170 Motherboard Datasheet

What is the maximum system memory supported by the ASRock IMB-170-V motherboard?

The motherboard supports up to 16GB of system memory.

From: ASRock IMB-170-V Motherboard Datasheet

What is the maximum operating temperature range for the ASRock IMB-170-V?

The motherboard operates within a temperature range of 0°C to 60°C.

From: ASRock IMB-170-V Motherboard Datasheet
